Gigabyte GA-H110M-H Micro ATX Motherboard

Brand: Intel

Title: Gigabyte GA-H110M-H Micro ATX Motherboard

Model: GA-H110M-H

Code: 12323319

Category: Component / Motherboard Intel / GigaByte

Product Type: Motherboard

Price: 9200

Warranty: 3

Availability: Available/In Stock

Description:

Basic Information

Supported CPU

Support for 7th/6th Generation Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
* For 7th Generation Intel® Core™ processors support need to update the latest BIOS.
L3 cache varies with CPU

Chipset

Intel® H110 Express Chipset

BIOS

1 x 64 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Form Factor

Micro ATX Form Factor; 22.6cm x 17.4cm

Expansion Slots

PCI

1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conform to PCI Express 3.0 standard.)
2 x PCI Express x1 slots
(All of the PCI Express x1 slots conform to PCI Express 2.0 standard.)

Memory

Type

Dual channel DDR4 memory architecture

Slots

2 x DIMM

Supported Memory

Support for DDR4 2400/2133 MHz memory modules
Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules

Maximum Memory

32 GB

Graphics

Graphics

1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.

Max Shared Memory

1024 MB

Connector & Ports

HDMI

1 x HDMI

D-Sub (s)

1 x D-Sub

USB (s)

Chipset:
4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

LAN Port (s)

Realtek® GbE LAN chip (10/100/1000 Mbit)

Supported Storage

Chipset:
4 x SATA 6Gb/s connectors

Audio

Realtek® ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out

Internal I/O Ports

1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.0/2.0 header
2 x USB 2.0/1.1 headers
1 x Clear CMOS jumper

TPM (Trusted Platform Module )

1 x Trusted Platform Module (TPM) header


Warranty Information

Manufacturing Warranty

03 Years
