CommScope 884024508-10 305 Meter Cat-6 UTP Cable
Model: COMMSCOPE-884024508-10
Brand: CommScope
Code: 2112541804
CommScope 884024508-10 305 Meter Cat-6 UTP Cable
The CommScope 884024508-10 Cat-6 UTP Cable is a high-performance shielded (F/UTP) horizontal cable that meets ANSI/TIA-568.2-D and ISO/IEC 11801 Class EA specifications. This cable's remarkable length of 304.8 meters (1000 feet) makes it perfect for large installations. It has eight separate 23 AWG single solid copper conductors and a 26 AWG solid drain wire to ensure maximum conductivity and endurance. The nominal jacket diameter of the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is 7.188 mm (0.283 inches), and the conductor insulation diameter is 1.140 mm (0.0449 inches). The Low Smoke Zero Halogen (LSZH) material used to make the white jacket improves safety by lowering dangerous emissions during a fire. The networking cable has a tolerance of ±15 ohms and an isolator separator type. Its impedance is 100 ohms. Maximum DC resistance of 7.8 ohms per 100 meters (2.377 ohms per 100 feet) and maximum delay skew of 45 ns guarantee electrical performance. The mutual capacitance of the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is 5.6 nF per 100 meters at 1 kHz, and its dielectric strength is at least 1500 Vac or 2500 Vdc. It offers a maximum working voltage of 80 V and functions efficiently up to 500 MHz. The Nominal Velocity of Propagation (NVP) of the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is 69%, and at 500 MHz, the maximum propagation delay is 536 ns per 100 meters. It guarantees safe power delivery across LAN cables when placed following ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2, or TIA TSB-184-A guidelines. It complies with IEEE 802.3bt (Type 4) specifications. With a maximum pulling tension of 11.34 kg (25 lb) and a minimum bend radius of eight times the outer diameter, the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is a dependable option for current data infrastructure demands since it is strong and adaptable for a variety of installation settings.
Brand: CommScope
Title: CommScope 884024508-10 305 Meter Cat-6 UTP Cable
Model: COMMSCOPE-884024508-10
Code: 2112541804
Category: Networking / Networking Cable / UTP (CAT6)
Product Type: UTP Cable
Price: 21400
Warranty: 0
Availability: Available/In Stock
Description:
CommScope 884024508-10 305 Meter Cat-6 UTP Cable
The CommScope 884024508-10 Cat-6 UTP Cable is a high-performance shielded (F/UTP) horizontal cable that meets ANSI/TIA-568.2-D and ISO/IEC 11801 Class EA specifications. This cable's remarkable length of 304.8 meters (1000 feet) makes it perfect for large installations. It has eight separate 23 AWG single solid copper conductors and a 26 AWG solid drain wire to ensure maximum conductivity and endurance. The nominal jacket diameter of the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is 7.188 mm (0.283 inches), and the conductor insulation diameter is 1.140 mm (0.0449 inches). The Low Smoke Zero Halogen (LSZH) material used to make the white jacket improves safety by lowering dangerous emissions during a fire. The networking cable has a tolerance of ±15 ohms and an isolator separator type. Its impedance is 100 ohms. Maximum DC resistance of 7.8 ohms per 100 meters (2.377 ohms per 100 feet) and maximum delay skew of 45 ns guarantee electrical performance. The mutual capacitance of the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is 5.6 nF per 100 meters at 1 kHz, and its dielectric strength is at least 1500 Vac or 2500 Vdc. It offers a maximum working voltage of 80 V and functions efficiently up to 500 MHz. The Nominal Velocity of Propagation (NVP) of the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is 69%, and at 500 MHz, the maximum propagation delay is 536 ns per 100 meters. It guarantees safe power delivery across LAN cables when placed following ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2, or TIA TSB-184-A guidelines. It complies with IEEE 802.3bt (Type 4) specifications. With a maximum pulling tension of 11.34 kg (25 lb) and a minimum bend radius of eight times the outer diameter, the CommScope 884024508/10 305 Meter Cat-6 UTP Cable is a dependable option for current data infrastructure demands since it is strong and adaptable for a variety of installation settings.
